SterilGuard series · Single-use equipment
SterilGuard® Asepto
Ready-to-use single-use sterility test canister for suitable pharmaceutical and laboratory membrane-filtration workflows.
Product overview
Integrated filtration for controlled laboratory workflows.
SterilGuard Asepto is an integrated disposable assembly designed to reduce the number of components that need to be prepared by the operator. The transparent canister allows visual observation of the filtration process and liquid condition during operation.
The test sample is passed through a membrane capable of retaining microorganisms. Following filtration, appropriate rinsing and culture-media introduction procedures can be performed according to the applicable sterility-test method and laboratory procedure.
Intended applications
- Pharmaceutical product testing
- Injectable product testing
- Sterile solution testing
- Antibiotic and antimicrobial product testing
- Ophthalmic preparation testing
Technical summary
Integrated, ready-to-use construction.
Summary from the current catalogue. Confirm the selected configuration and controlled documentation before ordering.
| Test principle | Membrane filtration |
|---|---|
| Membrane material | Mixed cellulose ester (MCE) or polyvinylidene fluoride (PVDF) |
| Membrane pore size | 0.20 µm or 0.45 µm |
| Membrane diameter | 47 mm |
| Configuration | Single-use |
| Canister body | Polymethyl methacrylate (PMMA) |
|---|---|
| Canister lid | Polymethyl methacrylate (PMMA) |
| Tubing | Polyvinyl chloride (PVC) |
| Sterilization | Ethylene oxide (EO), validated to ISO 11135 |
| Quality level | Sterility assurance level (SAL) 10^-6 |
Quality and handling
Packaged for sterile supply.
Each assembly is individually packed using a Tyvek and polyethylene sterile-barrier packaging system. The catalogue identifies a validated shelf life of 1 year, subject to specified storage conditions and package integrity.
- Primary packaging: Tyvek + polyethylene
- EO sterilization with ISO 11135 validation
- SAL 10^-6
- Validated shelf life: 1 year
Follow the current catalogue and package labelling for storage, transport, shelf life, integrity checks and use. Laboratory suitability, rinsing, culture-media introduction and incubation procedures remain method-specific.
Ordering information
Specify the configuration.
| Field | Catalogue options |
|---|---|
| Filter media | VGC-D120 |
| Membrane type | D = MCE; P = PVDF |
| Rating | 0.20 µm; 0.45 µm |
| Sterility | S = sterile; N = non-sterile |
Confirm available codes and current supply with Vanguard before ordering.
SterilGuard series
Compare the equipment formats.
Review Asepto alongside the reusable OptiGlass canister, then discuss the complete test setup with the technical team.
